B-2231-UK-11-2013-REV. C
An
Company
Gearboxes
Type 5595
(DN50 - DN300)
Aluminium alloy housing
Steel input shaft
Steel worm gear
Ductile iron output gear segment
Dustproof enclosure
Units provided with hand wheel
Adjustable travel stops are standard and factory set
AISI 304 standard bolts and nuts
Dimensions are valid for Type 2231 and 2241
Dimensions (mm)
Construction - Gear Operators - DN 40 to DN 300
Type Valve
dim.
S x S D2 n-d1 Ratio
Output
torque
(Nm)
Input
torque
(Nm)
A B øB C D E øF H H1 Weight
(Kg)
5595-10-11 DN 40 11 x 11
50
/
70
4 - M6x20 40:1 150
5 148 108 12 98 80 43
100
48 26
1.0
5595-10-11 DN 50 11 x 11
100
1.0
5595-10-11 DN 65 11 x 11
100
1.0
5595-15-11 DN 80 11 x 11
120
1.2
5595-15-11 DN 100 11 x 11
120
1.2
5595-20-14 DN 125 14 x 14
70 4 - M6x20 40:1 150
5 148 108 12 98 80 43
120
48 26
1.9
5595-20-17 DN 150 17 x 17
200
1.9
5595-30-22 DN 200 22 x 22
4 - M10x30 45:1 750
30 296 223 15 155 146 60
300
71 38
5.6
5595-30-22 DN 250 22 x 22 102
300
5.6
5595-30-27 DN 300 27 x 27
300
5.5
20
Know-how makes the difference
