Specifications
Enclosure
IP67, NEMA 4 and 6
Power supply
220V / 230V AC 1PH, 380 & 440V AC 3PH 50 / 60 Hz, ± 10%
Control power supply
220V / 230V AC 1PH, 50 / 60 Hz, ± 10%
Duty cycle (on-off duty)
S2, 30 min.
Duty cycle (modulating)
S4, 70% max. 300 - 1600 start / hour
Motor
Induction motor (reversible motor)
Limit switches
Open / close, SPDT, 250V AC 16A rating
Additional limit switches
Open / close, SPDT, 250V AC 16A rating
Torque switches
Open / close, SPDT, 250V AC 16A rating (except 008 and 010)
Stall protection / operating temp.
Built-in thermal protection, open 150° C. ± 5° C. / close 97° C. ± 15° C.
Travel angle
90° ± 10° (0° - 110°)
Indicator
Continuous position indicator
Manual override
Declutching mechanism
Self locking
Provided by double worm gearing
Mechanical stopper
2 x external adjustable screws
Space heater
10W (220V AC) Anti-condensation)
Cable entries
3 x PF 3/4” tap (standard type only)
Lubrication
Grease moly (EP type)
Terminal block
Spring loaded lever push type
Materials
Steel, Aluminium alloy, AI bronze, Polycarbonate
Ambient temperature
-20° C. - 70° C. (except option electronic board)
Ambient humidity
90% RH max. (non-condensing)
Anti vibration
X Y Z 10 g, 0.2 - 34 Hz, 30 min.
External coating
Anodizing treatment before dry powder, Polyester, Munsell no. 5R 3.5/12
Standard Specifications for size 008 - size 300
Optional Specifications for size 008 - size 300
EXA
Explosion proof enclosure actuator (E EX d IIB T4)
All
WTA
Watertight enclosure actuator (IP68 10M 72HR)
All
PIU
Potentiometer (0 - 1 KΩ)
All
PCU
Proportional Control Unit (input, output 0-10V DC, 4-20V mA DC)
All
ATS
Additional Torque Switches (SPDT x 3EA 250V AC 10A rating)
Except 008 / 010
SICU
Semi-Integral Control Unit (LCU + IMS + phase protect indicator)
Except 008 / 010
ICU
Intelligent Digital Control Unit (LCU + IMS + auto phase discriminator)
Except 008 / 010
CPT
Current Position Transmitter (output 4-20 mA DC)
All
EXT
Extension 120°, 180°, 270° turn
Except 200 / 300
RBP
Rechargeable Battery Backup
Except 008, 015, 020, 030
DCM
DC motor (24V DC)
Except 008, 015, 020, 030
ADCM
Multi AC / DC 24V (integral)
Except 008, 015, 020, 030
LPA
Lever Plate Actuator
Except 008 / 010
SLU
Signal Lamp Unit (white: power on, red: open, green: close, yellow: over torque) Except 008 / 010
FPA1
Fire Proofing Actuator 1050 ± 5° C. / 50 min.
Engineering consult in advance
PFA2
Fire Proofing Actuator 250 ± 5° C. / 150 min.
Engineering consult in advance
Power Supply
110V
Control Power Supply
110V
