B-5595-UK-06-2013 REV. B
An
Company
Ductile iron housing
Steel input shaft
Steel worm gear double stage
Ductile iron output gear segment
Waterproof enclosure
Units provided with handwheel
Adjustable travel stops are standard and factory set
AISI 304 standard bolts and nuts
Type
Ratio
Output
torque
(Nm)
Input
torque
(Nm)
Handwheel
ø (mm)
Turns from
open to
closed
Stem
hole size
Bolt size
n-M
Weight
(Kg)*
v
w
5595-80-89
184:1
7910
152
762
46
108.8
25
8 - M16
63
914
4 - M20
5595-90-110
250:1
10169
140
610
65.5
122.8 28
8 - M20
106
813
8 - M12
5595-100-165
720:1
23786
151
762
480
183.8 40
8 - M30
178
914
8 - M16
General Information
Gearboxes DOUBLE STAGE
Type 5595
(Size 80-100)
Construction - Quarter-Turn Gear - Size 80 - 90 - 100
General Parameters
*without hand wheel
Type
Mounting flange
min / max
d
max
d1
d2
A
B
C
E
F
G
5595-80-89
F16 / F25
89
25.4
8
44.45
383
276
286
349
194
5595-90-110
F20 / F30
110
25.4
8
44.45
413
287
355
439
261
5595-100-165
F25 / F35
165
31.7
8
44.45
501
376
463
528
320
Dimensions
Type
M
N
P
Q
D
D1
h
H
H1
5595-80-89
137
87
171
211
310
128
10
138
120
5595-90-110
181
87
171
211
355
152
25
190
140
5595-100-165
237
94
187
288
415
203
13
190
157
Know-how makes the difference
5
