B-5595-UK-06-2013 REV. B
An
Company
Gearboxes
Type 5595
(Size 10-30)
Aluminium alloy housing
Steel input shaft
Steel worm gear
Ductile iron output gear segment
Waterproof enclosure
Units provided with handwheel
Adjustable travel stops are standard and factory set
AISI 304 standard bolts and nuts
Dimensions (mm)
Construction - Quarter-Turn Gear - Size 10 - 15 - 20 - 30
Type
S x S
D2
n-d1 Ratio
Output
torque
(Nm)
Input
torque
(Nm)
A B øB C D E øF H H1 Weight
(Kg)
5595-10-11 11 x 11
50/70 4 - M6x20 40:1 150
5 148 108 12 98 80 43
100
48 26
1.0
5595-15-11 11 x 11
120
1.2
5595-20-14 14 x 14
70
4 - M6x20 40:1 150
5 148 108 12 98 80 43
120
48 26
1.9
5595-20-17 17 x 17
200
1.9
5595-30-22 22 x 22
102
4 - M10x30 45:1 750
30 296 223 15 155 146 60
300
71 38
5.6
5595-30-27 27 x 27
300
5.5
Know-how makes the difference
